Tarvitseko apua heti? 24/7 Hätäpalvelumme auttaa Tekniset tiedot
| Quantity | 1 pce |
| Brand | BTB Trafo by TMC Transformers |
| Year of Manufacture | 2024 |
| Condition | New |
| Basic Transformer Design | Cast-Resin |
| Ingress Protection | IP00 |
| Classifications | E2 – C2 – F1 |
| Application | Distribution Transformer |
| Number of Phases | Three-phase |
| Rated Power | 800 kVA |
| Cooling | AN |
| Voltage Ratio | 11 000 / 420 V |
| Voltage Regulation | off-circuit, bolted links |
| Tapping Range | +-2×2.5% |
| Temperature Class (HV/LV) | Class F / Class F |
| Frequency | 50 Hz |
| Vector Group | Dyn11 |
| Standards | IEC 60076-11 |
| Impedance | 6,26 % |
| Total Weight (IP00) | ~2350kg |
