This product has been sold

SIEMENS 33 MVA 110/11 kV

Request a quote
Print page
Share link
Need help now? Our 24/7 Emergency Service can help

Technical specifications

Quantity2 pcs
BrandSIEMENS, 1TRP 33 000 – 123
Year of Manufacture1998
ApplicationPower Transformer
Basic Transformer Conceptoil-immersed, conservator tank
Tank DesignRigid tank, detachable cooling radiators
Number of Phases3-phase
Rated Power33 000 kVA
Method of CoolingONAN
Voltage Ratio110000 / 11000 V
Voltage RegulationOLTC
Tapping Range110000V +-9X2%
Frequency50 Hz
Temperature Rise (oil/wind)60/65 K
ConnectionYNd1
Total Transp. Weight43 000 kg
Total Weight47 000 kg
Oil Weight10 000 kg
