This product has been sold

Helmerverken 630 kVA 10,5/0,69 kV

Request a quote
Print page
Share link
Need help now? Our 24/7 Emergency Service can help

Technical specifications

Quantity1 pce
BrandHelmerverken (Koncar)
Type8TBNv630-12/A
ConditionSecond Hand
Year of Manufacture1995
ApplicationPower Transformer
Basic Transformer Conceptoil-immersed, hermetically
Tank Designcorrugated tank
Number of Phases3-phase
Rated Power630 kVA
Method of CoolingONAN
Voltage Ratio – HV/MV/LV10500/ 690 V
Voltage Regulationoff-circuit tap changer
Tapping Range10500 V +-2×2.5%
Frequency50 Hz
ConnectionDyyn11
Short-circuit impedance3,9%
StandardsIEC 60076
Total Weight1960 kg
Weight of Oil350 kg
