This product has been sold

SGB 2,5 MVA 20/10 kV

Request a quote
Print page
Share link
Need help now? Our 24/7 Emergency Service can help

Technical specifications

Quantity1 pce
BrandSGB
TypeDOTEL 2500 H/20
ConditionSecond Hand
Year of Manufacture2009
ApplicationPower Transformer
Basic Transformer Conceptoil-immersed, conservator type
Tank Designcorrugated tank
Number of Phases3-phase
Rated Power2500 kVA
Method of CoolingONAN
Voltage Ratio – HV/MV/LV20 000/ 10 000V
Voltage Regulationoff-circuit tap changer
Tapping Range20 000 V +-2×2.5%
Frequency50 Hz
ConnectionDyn5
No-load losses Po2 488 W
Load-losses Pk22 586 W
Impedance5,9%
StandardsIEC 60076
Total Weight5 980 kg
Weight of Oil1 220 kg
