This product has been sold

Siemens Used 895 kVA 11/0,69 kV

Request a quote
Print page
Share link
Need help now? Our 24/7 Emergency Service can help

Technical specifications

Quantity1 pcs
BrandSiemens – GEAFOL
ConditionSecond Hand
Year of Manufacture2008
ApplicationDistribution Transformer (Windmill)
Basic Transformer ConceptDry-Type Cast Resin
ClassificationE2/C2/F1
Ingress ProtectionIP00
Number of Phases3-phase
Rated Power895 kVA
Method of CoolingAN
Voltage Ratio – HV/LV111000 / 690 V
Voltage RegulationBolted Links
Tapping Range+-2×2.5%
Frequency50 Hz
Thermal Class (HV/LV)Class F/F
ConnectionDyn5
Impedance5,3%
No-Load Losses2393 W
Load Losses7280 W @ 120°C
StandardsIEC 60076-11
Total Weight2280 kg
Outer Dimensions (LxWxH)1620 x 990 x 1450 mm
