This product has been sold

TBA 10 pcs NEW 2000 kVA 20/0,4 kV Dyn5

Request a quote
Print page
Share link
Need help now? Our 24/7 Emergency Service can help

Technical specifications

Quantity10 pcs
BrandTBA!
ConditionUnused
Year of Manufacture2016
ApplicationPower Transformer
Basic Transformer ConceptOil-immersed, hermetically sealed
Number of Phases3-phase
Rated Power2000 kVA
Method of CoolingONAN
Voltage Ratio – HV/LV120000 / 400 V
Voltage RegulationOff-circuit tap changer
Tapping Range+-2×2.5%
Frequency50 Hz
ConnectionDyn5
No-load Losses2100 W
Load Losses18000 W
StandardsIEC 60076-1
Temp. rise40ºC / 65 K / 60 K
Insulation levels HV24 / 125 / 50 kV (Vmax / LI / AC)
Insulation levels LV1,1 / 20 / 10 kV (Vmax / LI / AC)
Material HV/LVAl/Al
Total Weight5000 kg
